The GE Profile UltraFast Combo is a front-load washer and ventless heat pump dryer in one, offering energy efficiency and a large 4.8 cu. ft. capacity.
It combines advanced washing and drying cycles, perfect for handling bulky loads like king-size bedding in a single, convenient unit.
This innovative design eliminates the need for separate appliances, saving space and streamlining laundry tasks with cutting-edge technology.
1.1 Overview of the GE Profile UltraFast Combo
The GE Profile UltraFast Combo is a cutting-edge, all-in-one appliance that combines a front-load washer and a ventless heat pump dryer in a single unit.
With a spacious 4.8 cu. ft. capacity, it handles large loads, including bulky items like king-size bedding, offering unmatched convenience.
This energy-efficient design uses advanced Ventless Heat Pump Technology to dry clothes gently and quickly, eliminating the need for a separate dryer.
Ideal for space-saving laundry solutions, the UltraFast Combo streamlines the process, providing a sleek and modern addition to any home.
1.2 Benefits of an All-in-One Washer Dryer
An all-in-one washer dryer offers convenience, space efficiency, and cost savings. It eliminates the need for separate appliances, ideal for small spaces.
This unit reduces laundry time by washing and drying clothes in one cycle, minimizing effort and streamlining the process.
Energy efficiency is another key benefit, as it uses less water and energy compared to traditional setups, lowering utility bills.
Additionally, it reduces clutter and enhances home aesthetics with a sleek, modern design, making it a practical choice for modern households.
1.3 Key Features of the GE All-in-One Washer Dryer
The GE Profile UltraFast Combo boasts a large 4.8 cu. ft. capacity, accommodating bulky items like king-size bedding.
It features ventless heat pump technology for energy-efficient drying and gentle fabric care.
The UltraFast Wash & Dry cycle completes a full load in under two hours, saving time.
With smartDispense technology, it holds up to 50 oz. of detergent for multiple loads.
Its quiet operation and advanced moisture-sensing ensure optimal performance.
This unit is ENERGY STAR certified, promoting eco-friendly operation and energy savings.
Installation Instructions
Install the GE All-in-One Washer Dryer by laying it on its back on a protective surface.
Ensure leveling legs are adjusted for stability and proper operation.
Connect inlet and drain hoses, and ensure the power cable is securely plugged into a grounded outlet.
2.1 Tools Required for Installation
The installation of the GE All-in-One Washer Dryer requires specific tools to ensure proper setup.
You will need an adjustable wrench for connecting water hoses, a screwdriver for securing the unit, and pliers for tightening connections.
A spirit level is essential to ensure the unit is properly leveled for balanced operation.
Additionally, a power drill may be needed for securing the combo brackets, and a utility knife can assist with cutting packaging materials.
Always refer to the manual for a complete list of tools and follow safety guidelines to avoid damage or injury.
2.2 Step-by-Step Installation Guide
Begin by placing the GE All-in-One Washer Dryer on a protective surface, ensuring the leveling legs are adjusted to the minimum height.
Connect the water inlet and drain hoses securely, following the manual’s guidelines for proper configuration.
Install the combo brackets to stabilize the unit and prevent movement during operation.
Plug in the power cable, ensuring it is connected to a properly grounded outlet with the required circuit specifications.
Double-check all connections and ensure the unit is level for optimal performance.
Finally, test the unit by running a short cycle to verify functionality before regular use.
2.3 Leveling the Unit for Proper Operation
Proper leveling of the GE All-in-One Washer Dryer is crucial for stable operation and to prevent vibration during cycles.
Place the unit on a firm, even surface and adjust the leveling legs at each corner to ensure balance.
Use a spirit level to verify that the unit is perfectly horizontal and plumb from front to back and side to side.
Tighten the leveling legs securely once the desired position is achieved.
Improper leveling can lead to noise, inefficient performance, and potential damage to the machine.
Ensure the unit is stable and does not rock or tilt before starting any wash or dry cycles.
Safety Precautions
Adhere to all safety guidelines to avoid accidents. Never operate the dryer without the lint filter. Follow fabric care instructions to prevent garment damage or melting. This product contains chemicals known to California to cause cancer or reproductive harm.
3.1 General Safety Guidelines
Always read and follow the safety instructions in this manual. Ensure proper installation and leveling of the unit to prevent vibration or instability during operation. Keep children and pets away from the appliance while it is in use. Avoid immersing the washer-dryer combo in water or exposing it to extreme temperatures. Never lean or stand on the unit, as this could cause damage or injury. Use only the recommended power cable and ensure it is properly grounded. Regularly clean the lint filter to maintain efficiency and safety. Follow all fabric care labels and instructions to prevent damage to garments or the appliance.
3.2 Important Safety Warnings
Always adhere to the safety warnings provided in this manual to avoid potential hazards. Do not operate the dryer without the lint filter in place, as this can cause fires or damage. Ensure the power cable is properly grounded to prevent electrical shocks. Keep flammable materials, such as curtains or towels, away from the appliance during operation. Never modify or tamper with the unit’s components, as this may void the warranty and pose safety risks. Avoid installing the unit in areas with extreme temperatures or humidity. Do not use the appliance as a shelf or for storing items. Follow fabric care instructions to prevent damage to garments or the unit.
3.3 California Proposition 65 Warnings
This product contains one or more chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. These warnings are required under California Proposition 65, which mandates clear notifications for consumer safety. GE Appliances complies with this regulation to ensure transparency about potential chemical exposures. Users are advised to review the product manual for detailed information on safe usage and handling. This warning does not imply the product is unsafe but serves as a notification under California law.
Operating the GE All-in-One Washer Dryer
Start by selecting the desired cycle for washing, drying, or both. The UltraFast Combo offers advanced modes like wash-only, dry-only, or combined cycles. Follow the manual for optimal settings and energy efficiency, ensuring a seamless laundry experience without transferring clothes between cycles.
4.1 Getting Started with the Combo Unit
Before your first use, ensure the unit is properly installed and leveled. Plug in the power cable, secure the inlet and drain hoses, and check the ventless system requirements. Familiarize yourself with the control panel, selecting the desired mode (wash-only, dry-only, or combined). Always place the lint filter in the dryer compartment. Follow fabric care labels to choose the right settings. For energy efficiency, use the Eco mode for lower consumption. Start small loads to test functionality, then gradually move to larger loads. Remember to clean the lint filter after each use for optimal performance and safety.
4.2 Wash and Dry Cycles Explained
The GE All-in-One Washer Dryer offers multiple wash and dry cycles tailored for various fabrics and soil levels. Wash cycles include Normal, Heavy Duty, and Delicate options, while dry cycles feature settings like Eco, Normal, and Fast Dry. The ventless heat pump technology ensures energy efficiency, gently drying clothes without high heat. Selecting the right cycle combination optimizes cleaning and drying performance. Use the UltraFast mode for quick washing and drying of lightly soiled garments. Always refer to the fabric care labels for best results and to prevent damage to delicate items.
4.3 Using the Ventless Heat Pump Technology
The GE All-in-One Washer Dryer features ventless heat pump technology, which uses ambient air to dry clothes without external venting. This eco-friendly system operates quietly and efficiently, preserving fabric integrity by avoiding high heat. To use it effectively, ensure proper installation and level the unit for optimal performance. Regularly clean the lint filter to maintain airflow and efficiency. Ideal for delicate fabrics, this technology ensures gentle drying while saving energy compared to traditional dryers. Always follow fabric care guidelines for best results with this innovative drying system.
Troubleshooting Common Issues
This section addresses common issues like noise during spin cycles, drying performance problems, and error codes, providing solutions to ensure optimal appliance functionality.
5.1 Noise During the Spin Cycle
A loud, semi-deep, cyclic clicking noise during the spin cycle may indicate an issue with the washer’s internal mechanisms. Ensure the unit is properly leveled, as imbalance can cause vibrations and noise. Check for foreign objects in the drum or drain pump filter, as debris can create unusual sounds. If the noise persists, refer to the troubleshooting guide or contact GE Appliances support for assistance. Regular maintenance, such as cleaning the lint filter and ensuring proper ventilation, can also help prevent operational issues and maintain optimal performance.
5.2 Issues with Drying Performance
If the GE All-in-One Washer Dryer is not drying clothes effectively, check the lint filter for blockages and clean it regularly. Ensure proper ventilation around the unit, as ventless models require airflow to function efficiently. Verify that the dryer cycle is set correctly for the load size and fabric type. Avoid overloading, as this can prevent clothes from drying properly. If issues persist, consult the troubleshooting section or contact GE Appliances support for further assistance. Regular maintenance and adherence to fabric care guidelines can help optimize drying performance and extend the unit’s lifespan.
5.3 Error Codes and Solutions
- E1 Error: Indicates a water supply issue. Check for kinks in the water supply hoses and ensure the water valves are fully open.
- E2 Error: Relates to drainage problems. Inspect the drain hose for blockages or incorrect installation.
- E3 Error: May signal a temperature sensor malfunction. Reset the unit or contact GE Appliances support for assistance.
Regular maintenance, such as cleaning the lint filter, can help prevent these issues. Always refer to the manual for specific troubleshooting steps to ensure optimal performance and extend the unit’s lifespan.
Maintenance and Care
- Clean the lint filter regularly to ensure optimal drying performance and prevent blockages.
- Inspect and replace washer hoses every 5 years to avoid leaks or water damage.
- Wipe down the gasket and interior after each use to prevent mold growth.
Proper upkeep extends the lifespan and efficiency of your GE All-in-One Washer Dryer.
6.1 Cleaning the Lint Filter
Cleaning the lint filter is essential for maintaining your GE All-in-One Washer Dryer’s performance. Locate the filter in the dryer compartment and remove it. Gently brush off lint with a soft tool or vacuum. Ensure it’s dry before reinstalling to prevent moisture buildup. Regular cleaning improves drying efficiency and prevents potential issues. Always follow the manufacturer’s guidelines for proper maintenance.
6.2 Checking and Replacing Washer Hoses
Regularly inspect the washer hoses for cracks, leaks, or damage. Turn off the water supply before checking. Replace hoses every 5 years or if signs of wear appear. Use genuine GE replacement parts, such as part number 234D2665P001, for compatibility. Ensure tight connections after installation to prevent leaks. This maintenance helps prevent water damage and ensures reliable performance. Always refer to the manual for specific instructions on replacing hoses for your model.
6.3 Regular Maintenance Tips
Regular maintenance ensures optimal performance and longevity of your GE All-in-One Washer Dryer. Clean the lint filter after each use to improve drying efficiency. Check for blockages in the vent or drain hose. Leave the door open after use to dry the interior and prevent mold. Run a cleaning cycle monthly to remove detergent residue. Inspect and clean the gasket and seals. Check for software updates to ensure the unit operates with the latest features. Schedule professional servicing annually for internal components. Regular care prevents issues and maintains energy efficiency.
Energy Efficiency and Savings
The GE Profile UltraFast Combo is ENERGY STAR certified, featuring a ventless heat pump that reduces energy consumption. Eco-friendly design lowers utility bills and minimizes environmental impact.
7.1 Energy Guide and Ratings
The GE Profile UltraFast Combo features an Energy Guide label, required by the U.S. Department of Energy, to help consumers compare energy efficiency and estimated operating costs.
This ENERGY STAR-certified appliance meets rigorous energy efficiency standards set by the U.S. Environmental Protection Agency (EPA).
The ventless heat pump technology reduces energy consumption compared to traditional dryers, offering long-term savings.
Refer to the Energy Guide and manual for specific details on annual energy usage and cost estimates.
These ratings help users make informed decisions about energy efficiency and environmental impact.
7.2 Eco-Friendly Features of the Combo Unit
The GE Profile UltraFast Combo incorporates eco-friendly technologies like ventless heat pump drying, which reduces energy consumption significantly.
This system recirculates heat, minimizing the need for external ventilation and lowering overall energy use.
The unit also offers advanced moisture-sensing capabilities, ensuring clothes are dried efficiently without over-drying, which preserves fabric life.
Additionally, the combo unit’s compact design reduces water and detergent usage compared to separate appliances.
These features make it an environmentally responsible choice for modern households seeking sustainable laundry solutions.
7.3 Reducing Energy Consumption
The GE All-in-One Washer Dryer is designed to minimize energy use through advanced features like ventless heat pump technology and moisture-sensing capabilities.
This system recirculates hot air for drying, reducing the need for external ventilation and lowering energy consumption.
Additionally, the unit’s energy-efficient wash and dry cycles optimize water and heat usage, ensuring minimal waste.
Users can further reduce energy consumption by selecting eco-mode for lighter loads and ensuring proper ventilation in the laundry area.
Regular maintenance, such as cleaning the lint filter, also helps maintain optimal performance and energy efficiency.
Customer Support and Resources
Access the GE Appliances website for model-specific manuals, installation guides, and troubleshooting tips. Contact support at 1-800.GE.CARES for assistance with your washer/dryer combo.
8.1 Accessing the GE Appliances Website
The GE Appliances website provides comprehensive support for your washer/dryer combo. Visit GEAppliances.com to find model-specific manuals, installation instructions, and troubleshooting guides.
Enter your appliance’s model number in the search bar to access detailed documentation. For older models, visit the Owner Support page.
This resource ensures you can quickly find the information you need to operate and maintain your GE All-in-One Washer Dryer effectively.
8.2 Finding Model-Specific Manuals
To find model-specific manuals for your GE All-in-One Washer Dryer, visit the GE Appliances website.
Enter your appliance’s model number in the search bar at the top of the page to access its dedicated documentation.
Manuals for models manufactured from 2000 onward are readily available, ensuring you can easily locate guides for your specific unit.
For older models, visit the Owner Support page, where you can search by model number for quick access to manuals and installation instructions.
8.3 Contacting GE Appliances Support
For assistance with your GE All-in-One Washer Dryer, contact GE Appliances support at GEAppliances.com.
Call their customer service team at 1-800-GE-CARES (1-800-432-2737) for troubleshooting or maintenance inquiries.
You can also use the contact form on their website for email support.
Support is available Monday through Friday, providing reliable help for any issues with your appliance.
Technical Specifications
The GE All-in-One Washer Dryer features a 4.8 cu. ft. capacity, with dimensions tailored for space-saving installation.
It requires a 15-amp circuit and includes 6-foot inlet, drain, and power cables for flexible setup.
Built for efficiency, it meets ENERGY STAR standards, ensuring optimal performance and energy savings.
9.1 Capacity and Dimensions
The GE All-in-One Washer Dryer offers a spacious 4.8 cu. ft. capacity, ideal for handling large loads, including bulky items like king-size bedding.
Dimensions are designed for compact spaces, ensuring a seamless fit in standard laundry areas.
The unit measures 33.75 inches in height, 27 inches in width, and 38.75 inches in depth, making it a space-saving solution.
Weighing approximately 220 pounds, it is sturdy yet manageable for installation.
These proportions allow for efficient use of space while maintaining robust washing and drying capabilities.
9.2 Inlet and Drain Hose Requirements
The GE All-in-One Washer Dryer requires a cold water inlet hose and a drain hose for proper operation.
Both hoses are typically 6 feet in length, ensuring flexibility during installation.
The inlet hose must be securely connected to a standard water supply line, while the drain hose should be directed to a nearby drain or laundry sink.
Ensure hoses are not kinked or bent to maintain proper water flow.
For optimal performance, use high-quality, kink-resistant hoses and follow the manufacturer’s installation guidelines.
Regularly inspect hoses for signs of wear to prevent leaks or damage.
9.3 Power Cable and Circuit Requirements
The GE All-in-One Washer Dryer requires a dedicated 120V, 15-amp electrical circuit for safe and efficient operation.
A properly grounded power cable, typically 6 feet in length, must be connected to the unit.
Ensure the circuit is protected by a time-delay fuse or circuit breaker to prevent overload.
Avoid sharing the circuit with other high-power appliances to maintain consistent performance.
The power cable should be securely plugged into a nearby outlet, and the connection must be tight to prevent any disconnection during use.
Always follow local electrical codes and safety guidelines for installation.
Warranty and Service
GE offers comprehensive warranty coverage for parts and labor, with options for extended service plans.
Schedule authorized service through GE Appliances support for reliable repairs and maintenance.
Warranty terms vary by model, with exclusions for normal wear and tear or improper installation.
10.1 Understanding the Warranty Terms
GE Appliances provides comprehensive warranty coverage for the All-in-One Washer Dryer, ensuring protection for parts and labor under specific conditions.
The warranty period varies by model and component, with detailed terms outlined in the product manual.
Coverage typically excludes damage from improper installation, misuse, or normal wear and tear.
Extended service plans are available for added protection beyond the standard warranty period.
For precise warranty details, including what is covered and for how long, refer to the official GE Appliances website or the provided product manual.
10.2 Scheduling Service Appointments
To schedule a service appointment for your GE All-in-One Washer Dryer, visit the GE Appliances website or call 1-800.GE.CARES (1-800-432-2737).
Online scheduling is available through the Owner Support section, where you can select your model and preferred service time.
Have your model number and a detailed description of the issue ready to ensure a smooth process.
Appointments can also be arranged through authorized service providers listed on the GE Appliances website.
For convenience, the website offers 24/7 access to schedule or reschedule appointments.
10.3 Warranty Coverage and Exclusions
The GE All-in-One Washer Dryer is covered by a limited warranty, typically 1 year for parts and labor, with extended coverage for certain components.
The warranty covers defects in materials and workmanship under normal use and conditions.
Exclusions include damage from misuse, neglect, or improper installation, as well as normal wear and tear.
Cosmetic damage and issues caused by unauthorized repairs or non-genuine parts are also excluded.
For full warranty details, refer to the GE Appliances website or the manual provided with your unit.
